For doors in buildings accessed by the public where panic can be foreseen
Suitable for push face of outward opening doors
For use on double doors with rebated meeting stiles

Ease of adjustment in main units by means of top and bottom adjustable locator units
Bottom rod unit already assembled - no cutting required
Rods already fitted with round shoot bolts
Spring loaded floor socket
Non-handed for maximum flexibility
Anti-vandalism - push bar retained in handles
Automatic top trip
Downward pressure at any point on bar withdraws the bolts/latch ensuring immediate release of door
Top rod and push bar can be cut to size to suit door dimensions
Bolt projection: 14mm
Anti-thrust
Adjustable top & bottom shoots
Complete with signage and pictorial fixing instructions
Compatible with Union Outside Access Device (see related products below)

Max. Door Leaf Width: 1300mm
Max. Door Height: 2440mm
Max. Door Leaf Mass: 200kg

Finish
SIL - Silver (RAL 9006)

CE marked to BS EN 1125 (CE mark not valid if door exceeds measurements given
3 7 6 B 1 3 2 2 A A

Included in fire tests to BS EN 1634-1
